Headphone amplifier with enhanced circuitry and audiophile sound

The iFi Audio ZEN CAN Signature combines high power, warm and detailed sound with premium components and enhanced design. Featuring a fully balanced, symmetrical dual-mono circuit, it delivers up to 1 890 mW at 64 Ω and over 15 V at 600 Ω loads via its balanced output. Suitable for both sensitive IEMs and power-hungry headphones, the ZEN CAN Signature is the perfect addition to your audio setup.

Features

• Enhanced circuitry: Class A balanced amplifier inherited from Pro iCAN
• Premium components: ELNA Silmic II & OS-CON capacitors, OV op-amps
• iPower2 power supply: with active noise cancellation for clean sound
• Multiple inputs: RCA, 3.5 mm and 4.4 mm balanced
• Multiple outputs: 6.3 mm, 4.4 mm and balanced line-out
• Adjustable gain: 0 dB, 6 dB, 12 dB, 18 dB
• Analog modes: XSpace and XBass for enhanced stage and bass

What’s in the box?

• iFi ZEN CAN Signature Headphone Amplifier
• iFi iPower2 Power Adapter
• User Manual

Technical Information

• Dimensions: 158×117×35 mm
• Frequency Response: 10 Hz–200 kHz (–3 dB)
• Gain: 0/6/12/18 dB
• Input Voltage: 5 V/2.5 A
• Net Weight: 550 g
• Output: Balanced: 7.4 V RMS; RCA: 3.8 V RMS; 3.5 mm: 1.92 V RMS
• Output Power: Balanced: >1890 mW @64 Ω; SE: >870 mW @64 Ω
• Output Impedance: Headphones: <1 Ω
• SNR: Balanced: >121 dBA; SE: >120 dBA
• THD+N: Headphone Section: <0.005% (1V @16 Ω)
